Home » PDU Product Selector » PX3-1732N
Rack Power Distribution Units (PDUs)
Power Configuration
400V, 3Φ Wye, 11.1kVA, 16A
Features
Securelock
Removable Controller
Energy Metering
Voltage (V), Current (A), Active Power (kW), Real Power (kVA), Energy (kWh), Power Factor
Metering Accuracy
ISO/IEC 62053-21 1%
Remote Outlet Switching
No
Metering per input line
Yes for all models
Metering per Branch Circuit Breaker
No
Environmental Sensor Ready
Yes
Compatible Sensors
Temperature, Humidity, Air Flow, Differential Pressure, Water Leak, and Contact Closure.
Cascading
Yes, Max 16 PDUs can be daisy chained using a USB or Ethernet connection.
Networking
(10/100/1000 Base T) Ethernet, Secondary redundant (10/100 Base T) Ethernet. Optional WiFi (802.11 a/b/g/n).
Onboard Display
Color, matrix LCD display : Voltage, current, or active power (per line); Alarms; Configuration information (name, ratings, IP / Networking information). Auto-flip orientation.
Specifications
Input
Input Plug
Cord (N/A)
Nominal Voltage
400V
Maximum Input Current
16A
Rated Input Current
16A
Power Capacity
11.1kVA
Cord Length
3m
Output
Nominal Voltage
230V
Receptacles (Output Connections)
(24) IEC320 C13
(12) IEC320 C19
Overload Protection
NA
Physical
Dimensions (WxDxH)
2.1in x 1.7in x 70.1in; 52mm x 43mm x 1780mm
Unit Weight
TBD
Shipping Weight
TBD
Shipping Dimensions
Mounting
RACK-KIT-PX2-1K-ZU
Environmental
Operating Temperature/Environment
60 C
Operating Relative Humidity
85%
Operating Elevation
0-6000ft
Conformance
Regulatory Approvals
CE
Warranty
Standard 2 years manufacturer warranty
Tender Text/Bid Submittal Text
Vendor: Raritan; Part Number: PX3-1732N
